大流量超高纯氢气发生器
产品功能如下:
该系列主要分为10个产品: 1.H2PEMPD-510-100 2.H2PEMPD-510-175 3.H2PEMPD-650-100 4.H2PEMPD-650-175 5.H2PEMPD-850-100 6.H2PEMPD-850-175 7.H2PEMPD-1100-100 8.H2PEMPD-1100-175 9.H2PEMPD-1300-100 10.H2PEMPD-1300-175
大流量超高纯氢气发生器 [H2PEMPD系列]
| 型 号 | H2PEMPD-510-100 | H2PEMPD-650-100 | H2PEMPD-850-100 | H2PEMPD-1100-100 | H2PEMPD-1300-100 |
| H2PEMPD-510-175 | H2PEMPD-650-175 | H2PEMPD-850-175 | H2PEMPD-1100-175 | H2PEMPD-1300-1175 | |
| 氢气纯度 | 99.99999+% | 99.99999+% | 99.99999+% | 99.99999+% | 99.99999+% |
| 流 量 | 510cc/min | 650cc/min | 850cc/min | 1100cc/min | 1300cc/min |
| 输出压力 | 100 or 175 psig | ||||
| 制氢原理 | 水电解技术+钯纯化 | ||||
特性和好处
1.流量达到1300毫升/分钟
2.最高可达175 psi的输出压力,为GC应用提供高流量氢气
3.消除危险和昂贵的氦气和氢气钢瓶
4.安全-只生产你需要的气体
5.生产99.99999+%纯氢气连续供应, 与干燥柱和PSA干燥方法不同,钯纯化技术确保氢气纯度，防止基线漂移
6.紧凑和可靠-只需要一平方英尺的工作台空间
7.24小时/天,连续运行自动给水
8.最高可支持30台氢气发生器连用
9.远程电脑监控功能
10.先进的PEM质子交换膜保护系统和微处理器控制
11.简单的维护，无需加装纯化器
12.经CSA、IEC 1010和CE标记认证的实验室使用
Features and Benefits
1.Flow capacity up to 1,300 cc/min
2.Delivery pressure of up to 175 PSIG; ideal
for high speed and fast GC applications
3.Eliminates dangerous and expensive helium
and hydrogen gas cylinders
4.Safe - produces only as much gas as you need
5.Produces a continuous supply of 99.99999+%
pure hydrogen gas; palladium membrane prevents baseline drift unlike
auto-drying technologies
6.Compact and reliable - only one square foot
of bench space required
7.Automatic water feed for continuous
operation, 24/7
8.Cascading feature enables users to connect
as many as 32 hydrogen generators together to supply a large number of
instruments
9.Remote PC monitoring features
10.Advanced PEM electrochemical cell
protection system with microprocessor controls
11.Simple maintenance, without Snap-on
downstream purifiers
